533 x 210 x 92 kg universal beam
Out of stock
| Weight | 92 kg |
|---|---|
| Dimensions | 100 × 210 × 533 mm |
| Beam Type | Ⅰ Univeral Beam |
| Kg per metre | 92 |
| Depth x Width x Kgs per M | |
| surface area per tonne m | |
| (b) Width mm | |
| (d) Depth mm | |
| (b) Rounded Width | 210 |
| (d) Rounded Depth | 533 |
| (f) Space between fillets mm | 476.5 |
| (s) Web mm | 10.1 |
| (t) Flange mm | |
| (r1) root radius mm | |
| Metres per tonne | 11 |
| area of section cm² | |
| Standard Sizes | |
| surface area per m cm² | |
| surface area end faces m² |
